Mercury Mountaineer II (2001-2005) horns system Wiring diagrams
This page contains all the electrical diagrams for the component. horns system, in which he is found in the car Mercury Mountaineer II (2001-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram horns system (1 of 2)
-SET CANCEL
1 2 3 4 5 6 POWER CRUISE CTRL SET IND
AIR BAG SLIDING CONTACT
AIR CONDITIONING SYSTEM
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CRUISE CTRL SET IND CRUISE CTRL SET IND
DK GRN WIRE
DK GRN/ORG WIRE
FUSE
GRY WIRE
GRY/RED WIRE
HORN SWITCH
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
MICROPROCESSOR
NCA WIRE
ON RES SET+
ORG/ WIRE
ORG/LT BLU WIRE
PNK WIRE
PNK/LT BLU WIRE
POWERTRAIN CONTROL MODULE (PCM) (AT RIGHT SIDE ENGINE BULKHEAD)
RED WIRE
RED/BLK WIRE
REDUNDANT PEDAL SWITCH (UNDER LEFT SIDE DASH PANEL)
SIGNAL RETURN
SPEED CONTROL ACTUATOR (RIGHT FRONT OF ENGINE COMPARTMENT, ON FENDER)
SPEED CONTROL SWITCH
SPEED CTRL INDICATOR
SPEED CTRL SW RTN BRAKE PRESS SW IN
TAN WIRE
TAN/ORG WIRE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Cruise control circuit, with ivd -> HORNS SYSTEM
Wiring diagram horns system (2 of 2)
1 2 3 4 5 6 SCP- SCP+ VBATT
2 10 DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FUSE 15
FUSE 16
GRY/YEL WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR ACC
LOW TIRE PRESSURE MODULE (UNDER PASSENGER DASH PANEL)
PNK/LT BLU WIRE
TAN/ORG WIRE
VBATT
YEL/LT GRN WIRE
Go to component -> Tire pressure monitoring circuit -> HORNS SYSTEM
