Mercury Mountaineer II (2001-2005) early prod late prod, w/ medium overhead console 3 2 Wiring diagram
This page shows the only wiring diagram for the component.early prod late prod, w/ medium overhead console 3 2, which is found in the car Mercury Mountaineer II (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram early prod late prod, w/ medium overhead console 3 2 (1 of 1)
ACCE- SSORY DELAY RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLK/PNK WIRE
BRN/ORG WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
CIRCUIT BREAKER 47
DOWN/ OPEN
EARLY PROD LATE PROD, W/ MEDIUM OVERHEAD CONSOLE 3 2
FUSE 2
HOT AT ALL TIMES
LATE PROD, W/ MEDIUM OVERHEAD CONSOLE EARLY PROD 7 2
LT BLU WIRE
LT BLU/BLK WIRE
PTC 1
RED/LT BLU WIRE
ROOF OPENING PANEL MOTOR ASSEMBLY
ROOF OPENING PANEL SWITCH
TAN/RED WIRE
UP/ CLOSE
VBATT
VPWR
WHT WIRE
WHT/RED WIRE
Go to component -> Power top/sunroof circuit -> EARLY PROD LATE PROD, W/ MEDIUM OVERHEAD CONSOLE 3 2
