Mercury Mountaineer II (2001-2005) 1 2 3 4 5 6 ground rear a/c front to rear a/c rear rear blower to aux a/c module Wiring diagrams

1 2 3 4 5 6 GROUND REAR A/C FRONT TO REAR A/C REAR REAR BLOWER TO AUX A/C MODULE A/C CLUTCH CYCLING PRESSURE SWITCH (RIGHT SIDE OF ENGINE COMPARTMENT) A/C CLUTCH SOLENOID (AT LEFT SIDE OF ENGINE) A/C HIGH PRESSURE SWITCH (LEFT FRONT OF ENGINE COMPT) AIR BAG SLIDING CONTACT AUDIO/ CLIMATE CONTROL SWITCH AUXILIARY A/C RELAY (BEHIND LEFT SIDE OF REAR SEATS) AUXILIARY BLOWER MOTOR (LEFT SIDE OF CARGO AREA) AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY (IN LEFT REAR CARGO AREA) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR HIGH BLOWER MOTOR RESISTOR HIGH BRN WIRE BRN/ORG WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CRUISE CONTROL SYSTEM DK BLU/LT GRN WIRE DK GRN WIRE DK GRN/YEL WIRE FAN DN FAN UP TEMP UP FUSE 25 FUSE 33 GROUND REAR A/C FRONT TO REAR A/C REAR GRY/LT BLU WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT ILLUMINATION INPUT LT BLU/ORG WIRE LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/RED WIRE PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (AT RIGHT SIDE ENGINE BULKHEAD) REAR A/C CONTROL MODULE (FRONT) (IN ROOF PANEL) REAR A/C CONTROL MODULE (REAR) (IN ROOF PANEL) REAR MODE DOOR ACTUATOR (LEFT SIDE, BEHIND REAR SEATS) RED WIRE RED/BLK WIRE RED/ORG WIRE RED/YEL WIRE TAN WIRE TEMP DN TEMPERATURE BLEND DOOR ACTUATOR (BELOW LEFT REAR CARGO AREA WINDOW) WHT WIRE YEL WIRE YEL/BLK WIRE

1 2 3 4 5 6 GROUND REAR A/C FRONT TO REAR A/C REAR REAR BLOWER TO AUX A/C MODULE AUXILIARY A/C RELAY (BEHIND LEFT SIDE OF REAR SEATS) AUXILIARY BLOWER MOTOR (LEFT SIDE OF CARGO AREA) AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY (IN LEFT REAR CARGO AREA) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLOWER MOTOR HIGH BLOWER MOTOR RESISTOR HIGH BRN WIRE BRN/ORG WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 25 DK GRN/YEL WIRE FUSE 33 GROUND REAR A/C FRONT TO REAR A/C REAR GRY/LT BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT ILLUMINATION INPUT LT BLU/ORG WIRE LT GRN WIRE ORG/BLK WIRE ORG/RED WIRE PNK/WHT WIRE REAR A/C CONTROL MODULE (FRONT) (IN ROOF PANEL) REAR A/C CONTROL MODULE (REAR) (IN ROOF PANEL) REAR MODE DOOR ACTUATOR (LEFT SIDE, BEHIND REAR SEATS) RED/BLK WIRE RED/ORG WIRE TEMPERATURE BLEND DOOR ACTUATOR (BELOW LEFT REAR CARGO AREA WINDOW) WHT WIRE YEL WIRE YEL/BLK WIRE
