Car Wiring Diagrams for Charging circuit for Mercury Mountaineer I facelift (1997-2001)

4.0L PUSHROD ALT SYS FUSE BATTERY BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/ORG WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) CHARGE WARNING LAMP 470 OHMS FUSE 15 GENERATOR HOT IN START OR RUN INSTRUMENT CLUSTER LT GRN/RED WIRE MEGA FUSE NCA WIRE RED WIRE STARTER MOTOR WHT/BLK WIRE YEL WIRE YEL/WHT WIRE
