Back-up lamps circuit for Mercury Mountaineer I facelift (1997-2001)
Back-up lamps circuit
A/T
BLK WIRE
BLK/PNK WIRE
DAY/NIGHT MIRROR/ AUTO LAMP SENSOR (MOUNTED IN REARVIEW MIRROR)
FUSE 27
FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH)
HOT IN RUN
M/T
REMOTE ANTI-THEFT PERSONALITY MODULE (AT LEFT REAR QUARTER PANEL)
REVERSING LAMP SWITCH (LEFT SIDE OF TRANSMISSION ADAPTER)
RIGHT BACK-UP LAMP LEFT BACK-UP LAMP
VIO/ORG WIRE
