Mercury Mountaineer I facelift (1997-2001) Cruise control circuit

1 2 3 4 5 6 INDICATOR CONTROL 1000 OHMS 2200 OHMS 4-WHEEL ANTI-LOCK BRAKE SYSTEM 680 OHMS 120 OHMS A/T W/ HIGH SERIES CONSOLE A/T W/O HIGH SERIES CONSOLE AIR BAG SLIDING CONTACT (IN STEERING COLUMN) BACK LIGHT BATTERY JUNCTION BOX BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE PEDAL POSITION (BPP) SWITCH (BEHIND STEERING COLUMN) BRAKE PRESS INPUT GROUND BRAKE PRESSURE SWITCH (LEFT REAR CORNER OF ENGINE COMPT) BRN WIRE CLUTCH PEDAL POSITION (CPP) SWITCH (ON CLUTCH PEDAL ARM) CLUTCH PEDAL POSITION (CPP) SWITCH JUMPER COAST CONTROL MODULE DK GRN/ORG WIRE FUSE FUSE 10 FUSE JUNCTION PANEL GRY WIRE GRY/BLK WIRE GRY/YEL WIRE HORN RELAY (BEHIND RIGHT SIDE OF DASH, IN RPO RELAY BLOCK) HORN SWITCHES HOT AT ALL TIMES HOT IN RUN INSTRUMENT CLUSTER LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/RED WIRE M/T MAIN LIGHT SWITCH NCA WIRE OFF ORG/ WIRE ORG/LT BLU WIRE PNK WIRE REAR AXLE SENSOR (ON AXLE ASSEMBLY) RED WIRE RED/ LT GRN WIRE RED/BLK WIRE REMOTE ANTI-THEFT PERSONALITY (RAP) MODULE (BEHIND LEFT SIDE OF DASH) RESUME SET/ ACCEL SPEED CONT SW IN SPEED CONT SW GND IGNITION SPEED CONTROL INDICATOR LAMP SPEED CONTROL SERVO (IN RIGHT REAR OF ENGINE COMPARTMENT) TAN/LT BLU WIRE VEHICLE SPEED INPUT BRAKE APPLIED IN YEL/ LT GRN WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE
