Mercury Mountaineer I facelift (1997-2001) red Wiring diagrams

This page contains all the electrical diagrams for the component. red, in which he is found in the car Mercury Mountaineer I facelift (1997-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram red (31 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (31 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

AIR BLADDER BLK WIRE BLK/WHT WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) DN UP ENTIRE SEAT FRONT HEIGHT MOTOR FRONT OF SEAT FUSE 18 FWD/RWD MOTOR HOT AT ALL TIMES INFLATE VENT LEFT FRONT POWER SEAT CONTROL SWITCH LEFT FRONT SEAT MOTOR ASSEMBLY LEFT LUMBAR LEFT POWER LUMBAR MOTOR LEFT POWER LUMBAR SEAT SWITCH LT BLU WIRE LT GRN WIRE NCA WIRE REAR HEIGHT MOTOR REAR OF SEAT RED WIRE RIGHT FRONT POWER SEAT CONTROL SWITCH RIGHT FRONT SEAT MOTOR ASSEMBLY RIGHT LUMBAR RIGHT POWER LUMBAR MOTOR RIGHT POWER LUMBAR SEAT SWITCH RWD FWD WHT WIRE YEL WIRE

Go to component -> 6-way & lumbar power seat circuit -> RED WIRE

Wiring diagram red (32 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (32 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

4.0L SOHC V6 4.0L OHV V6 5.0L V8 BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT) BLK WIRE BLK/WHT WIRE CANISTER VENT SOLENOID EGR VACUUM REGULATOR SOLENOID EGR VACUUM REGULATOR SOLENOID HEATED OXYGEN SENSOR 3 EVAP CANISTER PURGE VALVE FROM FUSE 8 (DIAGRAM 1 OF 4) FROM PCM POWER RELAY (4.0L EI V6) (DIAGRAM 2 OF 5) FROM PCM POWER RELAY (4.0L SOHC V6) (DIAGRAM 2 OF 5) FROM PCM POWER RELAY (5.0L V8) (DIAGRAM 2 OF 5) FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL INJECTOR 5 FUEL INJECTOR 5 FUEL INJECTOR 4 FUEL INJECTOR 6 FUEL INJECTOR 6 POWER- TRAIN CONTROL MODULE (4.0L OHV) FUEL INJECTOR 7 FUEL INJECTOR 8 FUEL PUMP RELAY A/C RELAY FUSE 13 HEATED OXYGEN SENSOR 1 HEATED OXYGEN SENSOR 2 HEATED OXYGEN SENSOR 3 HEATED OXYGEN SENSOR 4 IDLE AIR CONTROL VALVE LT BLU/ORG WIRE MASS AIR FLOW SENSOR MASS AIR FLOW SENSOR FUEL INJECTOR 3 IDLE AIR CONTROL VALVE MAXI FUSE 1 MAXI FUSE 10 MAXI FUSE 5 PCM POWER RELAY POWER- TRAIN CONTROL MODULE (5.0L V8) REAR OF ENGINE COMPT) RED WIRE STARTER MOTOR RELAY TAN WIRE TO FUEL INJECTORS (DIAGRAM 2 OF 5) TO FUSE 5 (DIAGRAM 3 OF 5) TO IGNITION SWITCH (DIAGRAM 3 OF 5) TO PCM POWER DIODE (DIAGRAM 3 OF 5) TRANS- MISSION TRANSMISSION WHT WIRE YEL WIRE

Go to component -> Power distribution circuit (2 of 5) -> RED WIRE

Wiring diagram red (33 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (33 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

4.0L 5.0L AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPARTMENT) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT) BATTERY JUNCTION BOX PCM POWER DIODE BLK WIRE BRAKE PEDAL POSITION SWITCH BRAKE PRESSURE SWITCH BRN WIRE CENTRAL TIMER MODULE/ GENERIC ELECTRONIC MODULE DATA LINK CONNECTOR DAY/NIGHT MIRROR/ AUTOLAMP SENSOR DIMMER RELAY FROM MAXI FUSE 1 DIAGRAM 2 OF 5) FROM MAXI FUSE 5 (DIAGRAM 2 OF 5) FROM PCM POWER RELAY (DIAGRAM 2 OF 5) FRONT WASHER PUMP RELAY FUSE 1 FUSE 11 FUSE 12 FUSE 13 FUSE 15 FUSE 16 FUSE 19 FUSE 20 FUSE 25 FUSE 5 FUSE 9 FUSE JUNCTION PANEL GENERIC ELECTRONIC MODULE GRY WIRE IGNITION COIL 1, 2 RADIO NOISE CAPACITOR IGNITION COIL 3, 4 IGNITION SWITCH INSTRUMENT CLUSTER LOCK LOCK OFF LT BLU WIRE LT GRN WIRE MEMORY SEAT SWITCH NCA WIRE OFF ORG/ WIRE ORG/LT GRN WIRE PASSIVE ANTI-THEFT SYSTEM MODULE PNK PNK WIRE PNK WIRE POWER ANTENNA MODULE POWER MIRROR SWITCH PPL RADIO NOISE CAPACITOR IGNITION COIL RED WIRE RED/LT GRN WIRE RELAY MODULE REMOTE ANTI-THEFT PERSONALITY MODULE RADIO RUN WIRE TAN/BLK WIRE TO FUSE 10 (DIAGRAM 5 OF 5) TO FUSE 21 (DIAGRAM 4 OF 5) TO FUSE 24 (DIAGRAM 4 OF 5) TO FUSE 27 (DIAGRAM 4 OF 5) WHT WIRE WIPER MOTOR LIFTGATE WIPER/ WASHER SWITCH WIPER RUN RELAY WIPER HI-LO RELAY YEL WIRE

Go to component -> Power distribution circuit (3 of 5) -> RED WIRE

Wiring diagram red (34 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (34 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

A/T M/T BLK WIRE BLK/WHT WIRE BLU WIRE CD CHANGER CIGAR LIGHTER CLUTCH PEDAL POSITION SWITCH CLUTCH PEDAL POSITION SWITCH JUMPER DIGITAL TRANSMISSION RANGE SENSOR DIGITAL TRANSMISSION RANGE SENSOR DAYTIME RUNNING LAMPS MODULE DOOR LOCK RELAY DOOR UNLOCK RELAY DRIVER SEAT MODULE DRIVER'S DOOR UNLOCK RELAY FROM FUSE 25 (DIAGRAM 3 OF 5) FROM IGNITION FROM IGNITION SWITCH STA (DIAGRAM 3 OF 5) FUSE 17 FUSE 18 FUSE 21 FUSE 24 FUSE 27 FUSE 28 FUSE 29 FUSE 34 FUSE JUNCTION PANEL GENERIC ELECTRONIC MODULE GRY WIRE LEFT FRONT POWER SEAT CONTROL SWITCH LIMITED ONLY LT BLU WIRE LT GRN WIRE LT GRN/PPL WIRE NCA WIRE ORG/ WIRE PNK PNK WIRE PNK PPL WIRE PNK WIRE PPL PPL (NEAR BREAKOUT TO INSTRUMENT CLUSTER) PPL PPL PPL/ (LEFT REAR OF ENGINE COMPARTMENT) PPL/ PPL/ PPL/ RADIO POWER ANTENNA MODULE RADIO SUBWOOFER AMPLIFIER REAR INTEGRATED CONTROL PANEL REAR WINDOW DEFROST RELAY TRANSMISSION CONTROL SWITCH PARKING AID MODULE RED WIRE REVERSING LAMP SWITCH DIGITAL TRANSMISSION RANGE SENSOR RIGHT FRONT POWER SEAT CONTROL SWITCH RIGHT POWER LUMBAR SEAT SWITCH DRIVER SEAT MODULE LEFT POWER LUMBAR SEAT SWITCH TAN/BLK WIRE TO FUSE 26 DIAGRAM 5 OF 5) TURN/ HAZARD FLASHER W/ ELECTRONICS GROUP ONLY W/ HIGH SERIES CONSOLE W/O HIGH SERIES CONSOLE W/ MEMORY SEAT W/O MEMORY SEAT WHT WIRE YEL WIRE

Go to component -> Power distribution circuit (4 of 5) -> RED WIRE

Wiring diagram red (35 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (35 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

4 DOOR 5 3 (2 DOOR) (4 DOOR) AUXILIARY RELAY BOX 2 (LEFT REAR OF VEHICLE, ABOVE WHEELWELL) BLK WIRE BLK/WHT WIRE DOOR LOCK RELAY DOOR UNLOCK RELAY DRIVER'S DOOR UNLOCK RELAY FUSE 18 FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) GENERIC ELECTRONIC MODULE (BEHIND CENTER OF DASH) HOT AT ALL TIMES LEFT FRONT DOOR LOCK MOTOR LEFT REAR DOOR LOCK MOTOR RIGHT REAR DOOR LOCK MOTOR LIFTGATE LOCK MOTOR LIFTGATE LOCK SWITCH LOCK LT GRN WIRE ORG/ WIRE PNK PNK PNK PNK WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/LT GRN WIRE PNK/ORG WIRE PNK/YEL WIRE RED WIRE RED/ORG OR PNK/ORG WIRE RED/ORG WIRE RIGHT FRONT DOOR LOCK MOTOR RIGHT FRONT POWER DOOR LOCK SWITCH UNLCK UNLOCK UNLOCK LOCK W/O ELECTRONIC GROUP W/ ELECTRONIC GROUP WHT WIRE YEL WIRE

Go to component -> Power door lock circuit -> RED WIRE

Wiring diagram red (36 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (36 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

BLK WIRE BLK/PNK WIRE DEFOGGER SYSTEM DIREC- TIONAL CONTROL SWITCH DK BLU WIRE DK GRN WIRE DK GRN/VIO WIRE DOWN RIGHT EXTERIOR REAR VIEW MIRROR SWITCH FUSE FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) HOT AT ALL TIMES L/R U/D LEFT LEFT EXTERIOR REAR VIEW MIRROR NCA WIRE ORG/LT GRN WIRE RED WIRE RIGHT RIGHT EXTERIOR REAR VIEW MIRROR UP LEFT VIO WIRE W/ ELEC- TRONICS GROUP ONLY YEL WIRE

Go to component -> Power mirrors circuit -> RED WIRE

Wiring diagram red (37 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (37 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

ACCESSORY DELAY RELAY BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BATTERY SAVER RELAY BATTERY SAVER RELAY CONTROL BLK WIRE DK BLU WIRE FUSE 4 FUSE 8 FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) GENERIC ELECTRONIC MODULE (BEHIND CENTER OF DASH) ACCY DELAY RELAY CONTROL HOT AT ALL TIMES LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE NCA WIRE ONE TOUCH OPEN/CLOSE ROOF OPENING PANEL MOTOR ORG/ WIRE PANEL CONTROL SWITCH (IN OVERHEAD CONSOLE) RED WIRE RELAY MODULE (BEHIND CENTER OF DASH) ROOF OPENING ROOF OPENING PANEL MOTOR (CENTER REAR OF ROOF) SLIDE SOLID STATE TAN WIRE TILT TRANSMISSION SYSTEM, POWER WINDOWS SYSTEM VIO WIRE YEL WIRE

Go to component -> Power top/sunroof circuits -> RED WIRE

Wiring diagram red (38 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (38 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

BATTERY JUNCTION BOX BATTERY SAVER RELAY BLK WIRE BLU WIRE CENTRAL JUNCTION BOX DN UP FUSE 26 GENERIC ELEC- TRONIC MODULE (BEHIND CENTER OF DASH) GRY WIRE HOT AT ALL TIMES LEFT FRONT POWER WINDOW MOTOR LEFT FRONT POWER WINDOW SWITCH LEFT FRONT SWITCH LT BLU WIRE LT BLU/BLK WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/ORG WIRE MAXI FUSE 4 ORG/ WIRE ORG/WHT WIRE RED WIRE RELAY MODULE (BEHIND CENTER OF DASH) RELAY MODULE (BEHIND CENTER OF DASH) ACCY DELAY RELAY RELAY MODULE (BEHIND CENTER OF DASH) ONE TOUCH DOWN RELAY RESISTANCE WIRE (0.015 +/- 0.001 OHM) RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT SWITCH ROOF OPENING PANEL CONTROL SWITCH TAN WIRE TAN/LT BLU WIRE TAN/YEL WIRE TRANSMISSIONS SYSTEM (TORQUE ON DEMAND RELAY) UP DN WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Power window circuit, 2 door -> RED WIRE

Wiring diagram red (39 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (39 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

BATTERY JUNCTION BOX BATTERY SAVER RELAY BLK WIRE BRN WIRE DN UP FUSE 26 FUSE JUNCTION PANEL GENERIC ELEC- TRONIC MODULE (BEHIND CENTER OF DASH) GRY WIRE HOT AT ALL TIMES LEFT FRONT POWER WINDOW MOTOR LEFT FRONT SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR SWITCH LT BLU WIRE LT BLU/BLK WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/ORG WIRE MASTER WINDOW/ DOOR LOCK CONTROL SWITCH MAXI FUSE 4 ORG/ WIRE ORG/WHT WIRE RED WIRE RED/BLK WIRE RELAY MODULE (BEHIND CENTER OF DASH) RELAY MODULE (BEHIND CENTER OF DASH) ACCY DELAY RELAY RELAY MODULE (BEHIND CENTER OF DASH) ONE TOUCH DOWN RELAY RESISTANCE WIRE (0.015 +/- 0.001 OHM) RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT SWITCH RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SWITCH ROOF OPENING CONTROL SWITCH TAN WIRE TAN/LT BLU WIRE TAN/YEL WIRE TRANSMISSIONS SYSTEM (TORQUE ON DEMAND RELAY) UP DN WHT WIRE WHT/BLK WIRE WINDOW LOCK SWITCH YEL WIRE YEL/RED WIRE

Go to component -> Power window circuit, 4 door -> RED WIRE

Wiring diagram red (40 of 49)

Wiring diagram red for Mercury Mountaineer I facelift (1997-2001) (40 of 49)
Get lifetime access to Mercury Mountaineer I facelift (1997-2001)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ILLUM RETURN GROUND FUSED IGNITION ANTENNA ANTI-LOCK BRAKES SYSTEM AUDIO ON AUDIO SYSTEM ON PROTOCOL A PROTOCOL B AUDIO SYTEM ON POWER BLK WIRE BLK/LT GRN WIRE BRN/PNK WIRE CD CHANGER CD PLAYER SHIELD CD RIGHT SIG IN CD RIGHT SIG OUT CD LEFT SIG IN CD LEFT SIG OUT DK GRN/ORG WIRE FUSE 20 FUSE 28 FUSE 29 FUSE 34 FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) GROUND GROUND GROUND ILLUM AMP R REAR (+) AMP L REAR (+) GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR ACC INTERIOR LIGHTS LEFT FRONT SPEAKER LEFT SIG (-) LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/VIO WIRE NCA WIRE ORG/BLK WIRE ORG/LT GRN WIRE ORG/RED WIRE POWER PROTOCOL A PROTOCOL A PROTOCOL B PROTOCOL B RADIO REAR INTEGRATED CONTROL PANEL RED WIRE RED/BLK WIRE RIGHT FRONT SPEAKER LEFT REAR SPEAKER RIGHT REAR SPEAKER RIGHT SIG SHIELD TAN WIRE TAN/LT GRN WIRE TAN/WHT WIRE TAN/YEL WIRE VEHICLE SPEED SIG VIO WIRE WHT/LT GRN WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Radio circuits, with amplifier -> RED WIRE

Page 4 of 5
1 2 3 4 5
