Mercury Mountaineer I facelift (1997-2001) generic electronic module defrost relay control Wiring diagram
This page shows the only wiring diagram for the component.generic electronic module defrost relay control, which is found in the car Mercury Mountaineer I facelift (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram generic electronic module defrost relay control (1 of 1)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BRN WIRE
BRN/LT BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DEFROST ON/OFF SWITCH ILLUM
DK BLU WIRE
DK GRN WIRE
GENERIC ELECTRONIC MODULE DEFROST RELAY CONTROL
HOT AT ALL TIMES FUSE 3
HOT IN RUN FUSE 27
LEFT POWER/ HEATED MIRROR HEATED REAR WINDOW
LT BLU WIRE
NCA WIRE
ON INDICATOR
ORG/ WIRE
REAR WINDOW DEFROST GRID
REAR WINDOW DEFROST RELAY
RED WIRE
RIGHT POWER/ HEATED MIRROR
SWITCH
TO INSTRUMENT CLUSTER) FUSE JUNCTION PANEL FUSE 32
VIO WIRE
YEL WIRE
Go to component -> Defogger circuit -> GENERIC ELECTRONIC MODULE DEFROST RELAY CONTROL
