Mercury Mountaineer I facelift (1997-2001) central timer module/ generic electronic module Wiring diagrams
This page contains all the electrical diagrams for the component. central timer module/ generic electronic module, in which he is found in the car Mercury Mountaineer I facelift (1997-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram central timer module/ generic electronic module (1 of 2)
4.0L SOHC
AIR SUSPENSION CONTROL COMPRESSOR ASSEMBLY
AIR SUSPENSION CONTROL RELAY
ANTI-THEFT HOOD SWITCH
AUXILIARY RELAY BOX 1
BARE
BATTERY JUNCTION BOX
BLK WIRE
BLK/WHT WIRE
CAMSHAFT POSITION SENSOR SHIELD
CENTRAL TIMER MODULE/ GENERIC ELECTRONIC MODULE
CTRL MODULE
DATA LINK CONNECTOR
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE LOW OIL/ TEMPERATURE SWITCH A/C PRESSURE CUTOFF SWITCH
FOG LAMP ISOLATION RELAY
FRONT WASHER PUMP RELAY
INSTRUMENT CLUSTER
LOW WASHER FLUID LEVEL SENSOR
M/T A/T
MASS AIR FLOW SENSOR
MESSAGE CENTER
MESSAGE CENTER SWITCH ASSEMBLY
PASSIVE ANTI-THEFT CONTROL MODULE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE
REAR HEIGHT SENSOR FUEL TANK ASSEMBLY
REAR WASHER CONTROL RELAY
RED WIRE
REMOTE ANTI-THEFT PERSONALITY MODULE DRIVER SEAT MODULE
RESTRAINT CONTROL MODULE
RIGHT FOG LAMP
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP
SLIDING AIRBAG CONTACT
SPEED CONTROL SERVO
STEERING RATE SENSOR
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 4) -> CENTRAL TIMER MODULE/ GENERIC ELECTRONIC MODULE
Wiring diagram central timer module/ generic electronic module (2 of 2)
4.0L
5.0L
AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPARTMENT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BATTERY JUNCTION BOX PCM POWER DIODE
BLK WIRE
BRAKE PEDAL POSITION SWITCH
BRAKE PRESSURE SWITCH
BRN WIRE
CENTRAL TIMER MODULE/ GENERIC ELECTRONIC MODULE
DATA LINK CONNECTOR
DAY/NIGHT MIRROR/ AUTOLAMP SENSOR
DIMMER RELAY
FROM MAXI FUSE 1 DIAGRAM 2 OF 5)
FROM MAXI FUSE 5 (DIAGRAM 2 OF 5)
FROM PCM POWER RELAY (DIAGRAM 2 OF 5)
FRONT WASHER PUMP RELAY
FUSE 1
FUSE 11
FUSE 12
FUSE 13
FUSE 15
FUSE 16
FUSE 19
FUSE 20
FUSE 25
FUSE 5
FUSE 9
FUSE JUNCTION PANEL
GENERIC ELECTRONIC MODULE
GRY WIRE
IGNITION COIL 1, 2 RADIO NOISE CAPACITOR IGNITION COIL 3, 4
IGNITION SWITCH
INSTRUMENT CLUSTER
LOCK
LOCK OFF
LT BLU WIRE
LT GRN WIRE
MEMORY SEAT SWITCH
NCA WIRE
OFF
ORG/ WIRE
ORG/LT GRN WIRE
PASSIVE ANTI-THEFT SYSTEM MODULE
PNK PNK WIRE
PNK WIRE
POWER ANTENNA MODULE
POWER MIRROR SWITCH
PPL
RADIO NOISE CAPACITOR IGNITION COIL
RED WIRE
RED/LT GRN WIRE
RELAY MODULE
REMOTE ANTI-THEFT PERSONALITY MODULE RADIO
RUN WIRE
TAN/BLK WIRE
TO FUSE 10 (DIAGRAM 5 OF 5)
TO FUSE 21 (DIAGRAM 4 OF 5)
TO FUSE 24 (DIAGRAM 4 OF 5)
TO FUSE 27 (DIAGRAM 4 OF 5)
WHT WIRE
WIPER MOTOR LIFTGATE WIPER/ WASHER SWITCH
WIPER RUN RELAY WIPER HI-LO RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 5) -> CENTRAL TIMER MODULE/ GENERIC ELECTRONIC MODULE
