Mercury Mountaineer I facelift (1997-2001) abs ind lf sensor lf sensor Wiring diagram
This page shows the only wiring diagram for the component.abs ind lf sensor lf sensor, which is found in the car Mercury Mountaineer I facelift (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram abs ind lf sensor lf sensor (1 of 1)
4-WHEEL ANTI-LOCK BRAKE
ABS ACTIV
ABS IND LF SENSOR LF SENSOR
ACCELERATION SENSOR (LEFT FRAME RAIL)
ANTI-LOCK BRAKES INDICATOR
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 3
BLK WIRE
BRAKE PEDAL POSITION (BPP) SWITCH (BEHIND STEERING COLUMN)
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 9
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (LEFT SIDE
DK GRN WIRE
FUSE 11
FUSE 14
FUSE 7
G SWITCH G SWITCH
GENERIC ELECTRONIC MODULE (CENTER OF DASH)
GROUND PMP MTR
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
INSTRUMENT CLUSTER
LT BLU/PNK WIRE
LT BLU/WHT WIRE
LT GRN/BLK WIRE
OF DASH) (REAR OF LEFT FRONT FENDER)
OHM 1400
ORG/BLK WIRE
ORG/WHT WIRE
PNK/LT BLU WIRE
REAR AXLE SENSOR (ON AXLE ASSEMBLY)
RED WIRE
RED/LT GRN WIRE
RED/PNK WIRE
RED/YEL WIRE
TAN/BLK WIRE
TAN/ORG WIRE
VSS OUT IGNITION REAR SEN REAR SEN ISO LINK GROUND CPU FEED
YEL WIRE
YEL/BLK WIRE
YEL/LT GRN WIRE
YEL/RED WIRE
Go to component -> Anti-lock brake circuits -> ABS IND LF SENSOR LF SENSOR
