Car Wiring Diagrams for Adjustable pedal circuit for Mercury Monterey VIII (2003-2007)

1 6 8 9 7 VBATT GROUND ADJ PEDAL MTR ADJ PEDAL MTR ADJ PEDAL SENS 10 12 ADJ PEDAL MTR ADJ PEDAL MTR 10 20 RTN SIG VREF ADJUSTABLE PEDAL MEMORY POTENTIOMETER ADJUSTABLE PEDAL MOTOR (UNDER LEFT SIDE OF DASH, ON ACCELERATOR PEDAL SUPPORT) ADJUSTABLE PEDAL SWITCH BLK WIRE BLK/LT BLU WIRE BRN/RED WIRE BUSSED ELECTRICAL CENTER (BEC) (AT LEFT SIDE OF ENGINE COMPARTMENT) DK BLU/VIO WIRE FORWARD/ FUSE 51 GRY WIRE GRY/RED WIRE HOT AT ALL TIMES JOINT CONNECTER 2 (BEHIND CENTER OF DASH) LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/YEL WIRE LT GRN/RED WIRE MEMORY MIRRORS CIRCUIT NCA WIRE REARWARD RED WIRE RED/LT BLU WIRE VIO/DK BLU WIRE WHT WIRE WHT/RED WIRE YEL/RED WIRE
