Car Wiring Diagrams for Trailer tow circuit for Mercury Monterey VIII (2003-2007)
Trailer tow circuit
BRN WIRE
BUSSED ELECTRICAL CENTER (BEC) (AT LEFT SIDE OF ENGINE COMPT)
DK BLU WIRE
DK GRN WIRE
FUSE 46
FUSE 52
HOT AT ALL TIMES
LEFT TURN TRAILER TOW RELAY
PARKING LAMP TRAILER TOW RELAY
RIGHT TURN TRAILER TOW RELAY
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TRAILER TOW CONNECTOR (REAR CENTER OF VEHICLE)
WHT WIRE
YEL WIRE
