Anti-theft circuit for Mercury Monterey VIII (2003-2007)

Anti-theft circuit

Get access

1 2 3 4 GND VPWR RX TX ANTI-THEFT HOOD SWITCH (AT LEFT REAR SIDE OF ENGINE COMPT) ANTI-THEFT INHIBIT SWITCH (ON LEFT FRONT DOOR) BLK WIRE BLU WIRE DK BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES FUSE 9 HOT IN RUN OR START FUSE 19 INSTRUMENT CLUSTER SYSTEM LOW CURRENT BOARD LT BLU WIRE LT GRN WIRE NCA WIRE ORG/RED WIRE PATS IND SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/ORG WIRE VREF WHT WIRE WHT/LT GRN WIRE
