Mercury Monterey VIII (2003-2007) w/o front parking aid w/ front parking aid Wiring diagram

12 13 SCP - SCP + 9 10 20 SCP - SCP + GND 915 914 AUTOMATIC A/C 915 914 MANUAL A/C ABS CONTROL MODULE (UNDER DRIVER'S SEAT) BLK WIRE BLK/LT BLU WIRE DRIVER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER SIDE CLIMATE CONTROLLED SEAT MODULE (UNDER DRIVER'S SEAT) ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE (CENTER OF DASH) ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) MODULE (CENTER OF DASH) FEPS FUSE 11 HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM ISO JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR 2 (BEHIND CENTER OF DASH) JOINT CONNECTOR 4 (BELOW LEFT SIDE OF DASH) LEFT SIDE POWER SLIDING DOOR MODULE LOW CURRENT BOARD LT BLU WIRE LT BLU/WHT WIRE ORG/ WIRE PARKING AID MODULE (RIGHT "D" PILLAR) PASSENGER SIDE CLIMATE CONTROLLED SEAT MODULE (UNDER PASSENGER'S SEAT) PNK WIRE PNK/LT BLU WIRE POWER LIFTGATE MODULE POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT) PREMIUM GROUP RESTRAINTS CONTROL MODULE (UNDER CENTER CONSOLE) RIGHT SIDE POWER SLIDING DOOR MODULE (ABOVE RIGHT REAR WHEELWELL) SCP - SCP + SCP+ SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) SPEED CONTROL SERVO (AT LEFT SIDE OF ENGINE COMPT) TAN WIRE TAN/ORG WIRE UBP VIO WIRE W/O FRONT PARKING AID W/ FRONT PARKING AID WHT WIRE
