Mercury Monterey VIII (2003-2007) vbatt sig rtn vref input vref scp+ scp- Wiring diagram
This page shows the only wiring diagram for the component.vbatt sig rtn vref input vref scp+ scp-, which is found in the car Mercury Monterey VIII (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vbatt sig rtn vref input vref scp+ scp- (1 of 1)
1 LO
1 LO RIGHT HEADLAMP
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
AUTOLAMP/ SUNLOAD SENSOR (NEAR TOP CENTER OF DASH)
BLK WIRE
BLK/LT BLU WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
BUSSED ELECTRICAL CENTER (BEC) (AT LEFT SIDE OF ENGINE COMPARTMENT)
DK BLU WIRE
DK BLU/LT GRN WIRE
DK GRN WIRE
FOG LAMP IND
FOG LAMP RELAY
FUSE 45
FUSE 48
FUSE 62
FUSE 65
GND GND
GRN WIRE
HEAD AUTOLAMP ON
HI LO
HIGH BEAM RELAY
HOT AT ALL TIMES
ILLUMINATION
INSTRUMENT CLUSTER
JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR 2 (BEHIND CENTER OF DASH)
LAMPS FOG
LEFT FRONT FOG LAMP
LEFT HEADLAMP HI
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MICROPROCESSOR
MULTI- FUNCTION SWITCH
OFF
OFF PARK
ORG/ WIRE
ORG/RED WIRE
PASS
PATS IND
PNK PNK WIRE
PNK/LT BLU WIRE
PWR PWR
RED WIRE
RED/PNK WIRE
RIGHT FRONT FOG LAMP
RLY CTRL
SCP+
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) LOW CURRENT BOARD
TAN WIRE
TAN/ORG WIRE
VBATT
VBATT SIG RTN VREF INPUT VREF SCP+ SCP-
VIO WIRE
VREF
VREF VREF VREF
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Headlights circuit, with autolamps -> VBATT SIG RTN VREF INPUT VREF SCP+ SCP-
