Mercury Monterey VIII (2003-2007) passenger side climate controlled seat fan Wiring diagram
This page shows the only wiring diagram for the component.passenger side climate controlled seat fan, which is found in the car Mercury Monterey VIII (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side climate controlled seat fan (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PWR SIG RTN
BLK WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BUSSED ELECTRICAL CENTER (BEC) (AT LEFT SIDE OF ENGINE COMPARTMENT)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/LT GRN WIRE
DK GRN/YEL WIRE
DRIVER SIDE CLIMATE CONTROLLED SEAT BACKREST ELEMENT (IN DRIVER'S SEAT BACKREST)
DRIVER SIDE CLIMATE CONTROLLED SEAT CUSHION ELEMENT (IN DRIVER'S SEAT CUSHION)
DRIVER SIDE CLIMATE CONTROLLED SEAT FAN
DRIVER SIDE CLIMATE CONTROLLED SEAT MODULE (UNDER DRIVER'S SEAT)
FUSE 11
FUSE 13
FUSE 15
GND SIGNAL PWR SIG RTN
HOT AT ALL TIMES
HOT IN RUN
LT BLU WIRE
LT BLU/BLK WIRE
PASSENGER SIDE CLIMATE CONTROLLED SEAT FAN
PASSENGER SIDE CLIMATE CONTROLLED SEAT MODULE (UNDER PASSENGER'S SEAT)
PNK/LT BLU WIRE
RED WIRE
SIG RTN VREF VREF SIG RTN
SIGNAL
SIGNAL PWR SIG RTN
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
UBP VPWR GROUND VBATT
VIO WIRE
WHT WIRE
WHT/LT BLU WIRE
YEL WIRE
Go to component -> Climate control seats circuit -> PASSENGER SIDE CLIMATE CONTROLLED SEAT FAN
