Mercury Monterey VIII (2003-2007) license lamps liftgate ajar switch Wiring diagram
This page shows the only wiring diagram for the component.license lamps liftgate ajar switch, which is found in the car Mercury Monterey VIII (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license lamps liftgate ajar switch (1 of 1)
A/C COMPRESSOR CLUTCH DIODE
ABS CONTROL MODULE
ABS TEST CONNECTOR
AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY
BATTERY
BLK WIRE
BUSSED ELECTRICAL CENTER (BEC) (AT LEFT SIDE OF ENGINE COMPARTMENT)
DROPPING RESISTOR
ENGINE COOLING FAN RELAY 5 ENGINE COOLING FAN RELAY 4
FUEL PUMP RELAY PCM POWER RELAY
GENERATOR
HIGH MOUNTED STOPLAMP
HORN
INTAKE MANIFOLD RUNNER CONTROL (IMRC) MODULE
LEFT FRONT FOG LAMP
LEFT FRONT SIDE LAMP RIGHT FRONT SIDE LAMP
LEFT HEADLAMP
LEFT REAR PARK/STOP TURN LAMP
LEFT REVERSING LAMP
LEFT SIDE POWER SLIDING DOOR MODULE FUEL DOOR INTERLOCK SWITCH
LICENSE LAMPS LIFTGATE AJAR SWITCH
LIFTGATE LATCH/UNLATCH ASSEMBLY
MASS AIR FLOW (MAF SENSOR)
NCA WIRE
POSITIVE CRANKCASE VENTILATION HEATER
POWER LIFTGATE MODULE
POWER LIFTGATE OPEN/CLOSE SWITCH
POWERTRAIN CONTROL MODULE (PCM)
REAR WINDOW DEFROST GRID
REAR WINDOW WASHER PUMP MOTOR
REAR WIPER MOTOR ASSEMBLY
RIGHT FRONT AUXILIARY PARK LAMP
RIGHT FRONT CORNERING LAMP
RIGHT FRONT FOG LAMP A/C CLUTCH FIELD COIL
RIGHT FRONT PARK/ TURN LAMP
RIGHT HEADLAMP
SHIELD
W/ CORNERING LAMPS
W/ CORNERING LAMPS W/O CORNERING LAMPS
W/O CORNERING LAMPS
WASHER FLUID LEVEL SWITCH
WHT WIRE
WINDSHIELD WASHER PUMP MOTOR
Go to component -> Ground distribution circuit (1 of 3) -> LICENSE LAMPS LIFTGATE AJAR SWITCH
