Mercury Monterey VIII (2003-2007) ign coil a shift sol a cool fan relay Wiring diagram

AIR CONDITIONING SYSTEM AIR CONDITIONING, COOLING FANS SYSTEMS ANTI-THEFT IND PSP SWITCH ANTI-THEFT SYSTEM BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/PNK WIRE COOLING FANS SYSTEM DATA LINK CONNECTOR (DLC) (BELOW DASH, LEFT OF STEERING COLUMN) DIGITAL TRANSMISSION RANGE (DTR) SENSOR (AT TOP OF TRANSAXLE) DK BLU/LT GRN WIRE DK GRN/WHT WIRE GENERATOR GROUND IGN COIL B GRY WIRE GRY/ORG WIRE GRY/RED WIRE GRY/YEL WIRE IAT SENS FUEL PUMP MON A/C PRESS SW IMRC MOD IGN COIL A SHIFT SOL A COOL FAN RELAY IGNITION COIL (TOP RIGHT SIDE OF ENGINE) IMRC MOD MAF INPUT FUEL RAIL TEMP INTAKE MANIFOLD RUNNER CONTROL (IMRC) MODULE (AT TOP OF ENGINE) LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN/VIO WIRE LT GRN/YEL WIRE MAF SIG RTN TFT SENS SIG MASS AIRFLOW (MAF) SENSOR (LEFT FRONT OF ENGINE COMPT) NCA WIRE ORG/BLK WIRE ORG/LT BLU WIRE ORG/WHT WIRE ORG/YEL WIRE PNK/LT BLU WIRE PNK/WHT WIRE POSITIVE CRANKCASE POWER STEERING PRESSURE SWITCH (AT LEFT REAR SIDE OF ENGINE COMPT) POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT) PROG SIGNAL RED WIRE RED/BLK WIRE RED/LT BLU WIRE RED/LT GRN WIRE RED/ORG WIRE RED/PNK WIRE RED/YEL WIRE STARTER RELAY GEN I CIRCUIT COOL FAN RELAY EGR VAC REG STARTING/CHARGING SYSTEM TAN/LT BLU WIRE TAN/ORG WIRE TSS SENS VENTILATION HEATER (TOP LEFT SIDE OF ENGINE) VIO WIRE VIO/ORG WIRE WHT/BLK WIRE WHT/LT GRN WIRE WHT/ORG WIRE YEL/BLK WIRE YEL/LT GRN WIRE
