Mercury Monterey VIII (2003-2007) fuse 48 Wiring diagrams

1 LO 1 LO RIGHT HEADLAMP AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM AUTOLAMP/ SUNLOAD SENSOR (NEAR TOP CENTER OF DASH) BLK WIRE BLK/LT BLU WIRE BLU WIRE BRN WIRE BRN/YEL WIRE BUSSED ELECTRICAL CENTER (BEC) (AT LEFT SIDE OF ENGINE COMPARTMENT) DK BLU WIRE DK BLU/LT GRN WIRE DK GRN WIRE FOG LAMP IND FOG LAMP RELAY FUSE 45 FUSE 48 FUSE 62 FUSE 65 GND GND GRN WIRE HEAD AUTOLAMP ON HI LO HIGH BEAM RELAY HOT AT ALL TIMES ILLUMINATION INSTRUMENT CLUSTER JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR 2 (BEHIND CENTER OF DASH) LAMPS FOG LEFT FRONT FOG LAMP LEFT HEADLAMP HI LT BLU WIRE LT GRN WIRE MAIN LIGHT SWITCH MICROPROCESSOR MULTI- FUNCTION SWITCH OFF OFF PARK ORG/ WIRE ORG/RED WIRE PASS PATS IND PNK PNK WIRE PNK/LT BLU WIRE PWR PWR RED WIRE RED/PNK WIRE RIGHT FRONT FOG LAMP RLY CTRL SCP+ SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) LOW CURRENT BOARD TAN WIRE TAN/ORG WIRE VBATT VBATT SIG RTN VREF INPUT VREF SCP+ SCP- VIO WIRE VREF VREF VREF VREF WHT WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE

1 LO 1 LO RIGHT HEADLAMP BLK WIRE BLK/LT BLU WIRE BLU WIRE BUSSED ELECTRICAL CENTER (BEC) (AT LEFT SIDE OF ENGINE COMPARTMENT) DK BLU WIRE DK GRN WIRE FOG LAMP IND FOG LAMP RELAY FUSE 45 FUSE 48 FUSE 62 FUSE 65 GND GND GRN WIRE HEAD HI LO HIGH BEAM RELAY HOT AT ALL TIMES ILLUMINATION INSTRUMENT CLUSTER JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR 2 (BEHIND CENTER OF DASH) LAMPS FOG LEFT FRONT FOG LAMP LEFT HEADLAMP HI LOW CURRENT BOARD PWR PWR LT BLU WIRE LT GRN WIRE MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH OFF ORG/ WIRE PARK PASS PNK WIRE PNK/LT BLU WIRE RED WIRE RED/PNK WIRE RIGHT FRONT FOG LAMP RLY CTRL SCP - SCP + SCP+ SIG RTN VREF VREF SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) TAN WIRE TAN/ORG WIRE VBATT VIO WIRE VREF WHT WIRE WHT/RED WIRE YEL WIRE
