Front wiper/washer circuit for Mercury Montego III (2004-2007)

Front wiper/washer circuit

Get access

BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPARTMENT) BLK WIRE DK BLU WIRE FRONT WASHER PUMP RELAY FUSE 23 FUSE 37 FUSE 4 HOT AT ALL TIMES HOT IN RUN OR ACC INTERVAL 4 24) INTERVAL 5 25) JOINT CONNECTOR 2 LT BLU WIRE LT GRN WIRE MICROPROCESSOR MULTI- FUNCTION SWITCH PARK PARK SENSE PNK WIRE RED WIRE RUN WIRE SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH) VPWR VREF WASHER FLUID LEVEL SWITCH (RIGHT FRONT ENGINE) WHT WIRE WHT/VIO WIRE WINDSHIELD WASHER PUMP MOTOR (RIGHT SIDE OF OF ENGINE COMPARTMENT) WINDSHIELD WASHER RELAY WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPARTMENT) WIPER HIGH/LOW RELAY WIPER RUN/PARK RELAY YEL WIRE
