A/t circuit, 6 speed a/t for Mercury Montego III (2004-2007)
A/t circuit, 6 speed a/t
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 VPWR
11 23 HS CAN + HS CAN -
6 SPEED AUTOMATIC TRANSAXLE MODULE (REAR OF ENGINE)
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
FUSE 16
FUSE 40
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN RUN AND START
HS CAN+
JOINT CONNECTOR 2
LT BLU/ORG WIRE
LT BLU/YEL WIRE
LT LT
ORG/ WIRE
P/N
P/N SIG HS CAN - PLUG WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
VPWR
WHT WIRE
