Charging circuit for Mercury Montego III (2004-2007)

Charging circuit

Montego Mercury III (2004-2007): Charging circuit

Get access

BATTERY BATTERY JUNCTION BOX (LEFT FRONT OF ENGINE COMPT) FUSE 18 BLK WIRE BLK/ORG WIRE CHARGE INDICATOR FUSIBLE LINK A (12 GA, GRAY) FUSIBLE LINK B (12 GA, GRAY) GEN COM GEN MON GENERATOR (RIGHT REAR OF ENG COMPT) GRY WIRE HOT IN START OR RUN SMART JUNCTION BOX (CJB) (LEFT SIDE OF DASH) FUSE 20 HS CAN+ INSTRUMENT CLUSTER VOLTAGE SUPPLY START/RUN LEFT FRONT FENDER) POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENG COMPT) RED WIRE RED/YEL WIRE STARTER MOTOR WHT WIRE WHT/BLK WIRE YEL WIRE YEL/LT BLU WIRE
