Power top/sunroof circuit for Mercury Montego III (2004-2007)
Power top/sunroof circuit
1 2 3 4 5 6 7 8 9 10 GND SW COM REL OUT TILT SIG OPEN SIG BAT
ACCESSORY DELAY RELAY
AUTO OPEN
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENG COMPT)
BLK WIRE
BRN/ORG WIRE
CLOSE OPEN
CLOSE SIG
DK BLU WIRE
FUSE 15
FUSE 25
FUSE 6
HOT AT ALL TIMES
LOW CURRENT BOARD
LT BLU WIRE
OVERHEAD CONSOLE
RED WIRE
RED/LT BLU WIRE
ROOF OPENING PANEL MODULE (ABOVE REAR VIEW MIRROR)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
TAN/RED WIRE
TILT
WHT/RED WIRE
