Instrument illumination circuit for Mercury Montego III (2004-2007)
Instrument illumination circuit
ACCESSORY DELAY RELAY
ADJUSTABLE PEDAL SWITCH
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLOCK- SPRING
DIMMER
DRIVER SIDE DOOR LOCK SWITCH
DRIVER SIDE FRONT POWER WINDOW MOTOR
FLOOR SHIFTER
FUSE 15
FUSE 25
HOT AT ALL TIMES
ILLUMINATION DIMMER SWITCH
INTERIOR
KEY PAD SWITCH ASSEMBLY
LIFTGATE/ DECKLID RELEASE SWITCH
LOCK
LOW CURRENT BOARD
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MASTER WINDOW ADJUST SWITCH
NCA WIRE
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH LEFT REAR WINDOW ADJUST SWITCH ILLUM ILLUM
PNK WIRE
RED WIRE
RIGHT REAR WINDOW ADJUST SWITCH ILLUM
SIG RTN
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
SPEED CONTROL SWITCH
UNLOCK
VBATT
VPWR
VREF ILLUM
WHT WIRE
YEL WIRE
