Courtesy lamps circuit for Mercury Montego III (2004-2007)
Courtesy lamps circuit (1 of 2)
BATTERY BATTERY SAVER SAVER RELAY RELAY
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/LT BLU WIRE
COURTESY LAMP RELAY
FUSE 1
FUSE 2
HOME- LINK MODULE
HOT AT ALL TIMES
LEFT VANITY MIRROR LAMP
LOW CURRENT BOARD
LT GRN/ORG WIRE
LUGGAGE COMPARTMENT LAMP (FIVE HUNDRED, MONTEGO)
ORG/ WIRE
RED WIRE
RIGHT VANITY MIRROR LAMP
SECOND ROW SEAT INTERIOR/MAP LAMP ASSEMBLY
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
THIRD ROW SEAT INTERIOR/MAP LAMP ASSEMBLY (FREESTYLE)
YEL/RED WIRE
Courtesy lamps circuit (2 of 2)
BLK WIRE
BLK/LT BLU WIRE
BRN/WHT WIRE
DIMMER
FRONT INTERIOR/MAP LAMP ASSEMBLY
ILLUMINATION DIMMER SWITCH
INTERIOR
KEY PAD SWITCH ASSEMBLY
LEFT EXTERIOR REAR VIEW MIRROR PUDDLE LAMP
LEFT FRONT DOOR AJAR SWITCH
LEFT REAR DOOR AJAR SWITCH
LT BLU/YEL WIRE
LT GRN/ORG WIRE
NCA WIRE
OVERHEAD CONSOLE
RED WIRE
RIGHT EXTERIOR REAR VIEW MIRROR PUDDLE LAMP
RIGHT FRONT DOOR AJAR SWITCH
RIGHT REAR DOOR AJAR SWITCH
SIG RTN
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
SWITCH 1/2
SWITCH 3/4
SWITCH 5/6
SWITCH 7/8
SWITCH 9/0
VREF
VREF ILLUM
W/ MEMORY MIRRORS
W/ ROOF OPENING PANEL
W/O MEMORY MIRRORS
W/O ROOF OPENING PANEL
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
