Mercury Montego III (2004-2007) w/ power recliner w/o power recliner Wiring diagram
This page shows the only wiring diagram for the component.w/ power recliner w/o power recliner, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ power recliner w/o power recliner (1 of 1)
BLK WIRE
DECKLID SOLENOID
DRIVER SEAT MODULE
DRIVER SIDE DOOR LOCK SWITCH
DRIVER SIDE FRONT POWER WINDOW MOTOR
DRIVER SIDE FRONT SEAT ADJUST SWITCH
DRIVER SIDE FRONT SEAT ADJUST SWITCH DRIVER SIDE FRONT HEATED SEAT MODULE
EXTERIOR REAR VIEW MIRROR SWITCH
FRONT INTERIOR/MAP LAMPS ASSEMBLY
HIGH MOUNTED STOPLAMP
KEY PAD SWITCH ASSEMBLY
LEFT EXTERIOR REAR VIEW MIRROR
LEFT FRONT DOOR AJAR SWITCH ANTI- THEFT INHIBIT SWITCH
LEFT LICENSE PLATE LAMP
LEFT REAR LAMP ASSEMBLY LEFT REAR DOOR AJAR SWITCH
LEFT VANITY MIRROR LAMP
LUGGAGE COMPARTMENT LAMP
MASTER WINDOW ADJUST SWITCH
MEMORY SET SWITCH
NCA WIRE
OVERHEAD CONSOLE
PARKING BRAKE SWITCH
REAR AUXILIARY SELECTOR SWITCH ASSEMBLY
REAR WIPER MOTOR ASSEMBLY
RIGHT LICENSE PLATE LAMP
RIGHT VANITY MIRROR LAMP
ROOF OPENING PANEL MODULE
SECOND ROW SEAT INTERIOR/MAP LAMPS ASSEMBLY
SMART JUNCTION BOX (SJB)
THIRD ROW SEAT INTERIOR/MAP LAMPS ASSEMBLY
W/ MEMORY
W/ POWER RECLINER W/O POWER RECLINER
W/ ROOF OPENING PANEL
W/O MEMORY
W/O MEMORY W/ MEMORY
W/O ROOF OPENING PANEL
Go to component -> Ground distribution circuit (3 of 4) -> W/ POWER RECLINER W/O POWER RECLINER
