Mercury Montego III (2004-2007) roof opening panel sw common Wiring diagram
This page shows the only wiring diagram for the component.roof opening panel sw common, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roof opening panel sw common (1 of 1)
ACCESSORY DELAY RELAY OUT
ACCESSORY RELAY
AUTO OPEN
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPARTMENT)
BLK TAN/RED WIRE
BLK WIRE
BLK/LT BLU WIRE
BRN/ORG WIRE
CIRCUIT BREAKER 25
CLOSE
DK BLU WIRE
FUSE 15
FUSE 6
GROUND
HOT AT ALL TIMES
LOW CURRENT BOARD
LT GRN/ORG WIRE
RED WIRE
RED/LT BLU WIRE
ROOF OPENING PANEL MODULE (BEHIND HEADLINER, ABOVE REAR VIEW MIRROR)
ROOF OPENING PANEL SW CLOSE SIG
ROOF OPENING PANEL SW COMMON
ROOF OPENING PANEL SW OPEN SIG
ROOF OPENING PANEL SW TILT SIG
SLIDE
SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH)
TAN/RED WIRE
VOLT BATT
WHT/RED WIRE
Go to component -> Overhead console circuit -> ROOF OPENING PANEL SW COMMON
