Mercury Montego III (2004-2007) left seatback heater wiring diagram
This page shows the only wiring diagram for the component.left seatback heater, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left seatback heater wiring diagram (1 of 1)
BATTERY JUNCTION BOX (BJB) (IN LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BRN WIRE
BRN/LT BLU WIRE
DRIVER SIDE FRONT HEATED SEAT MODULE (UNDER DRIVER SEAT)
ELECTRONIC AUTOMATIC TEMPERATURE CONTROL MODULE (EATC)
FIVE HUNDRED MONTEGO (BOTTOM LEFT "C"PILLAR)
FIVE HUNDRED, MONTEGO
FREESTYLE
FUSE 23
GRY/LT BLU WIRE
HIGH IND
HOT AT ALL TIMES
HOT IN RUN SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) FUSE 19
LEFT FRONT SEAT CUSHION HEATER (UNDER LEFT FRONT SEAT)
LEFT SEATBACK HEATER
LOW IND
LT BLU/WHT WIRE
NCA WIRE
PASSENGER SIDE FRONT HEATED SEAT MODULE (UNDER PASSENGER SEAT)
RIGHT FRONT SEAT CUSHION HEATER (UNDER RIGHT FRONT SEAT)
VIO/LT BLU WIRE
VIO/LT GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/LT BLU WIRE
Go to component -> Climate control seats circuit -> LEFT SEATBACK HEATER
