Mercury Montego III (2004-2007) interior lights system defogger system Wiring diagram
This page shows the only wiring diagram for the component.interior lights system defogger system, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior lights system defogger system (1 of 1)
BLK WIRE
DK BLU/ORG WIRE
DK GRN/ORG WIRE
DK GRN/VIO WIRE
DOWN
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM DEFOGGER SYSTEM
LEFT MIRROR
LEFT RIGHT
ORG/LT GRN WIRE
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
RED/ORG WIRE
RIGHT
RIGHT MIRROR
SMART JUNCTION BOX (SJB) (UNDER LEFT SIDE OF DASH)
UP DOWN
UP LEFT
VIO/ORG WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Power mirrors circuit -> INTERIOR LIGHTS SYSTEM DEFOGGER SYSTEM
