Mercury Montego III (2004-2007) fpmp cntrl Wiring diagram
This page shows the only wiring diagram for the component.fpmp cntrl, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fpmp cntrl (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR (ON ACCELERATOR PEDAL ASSEMBLY)
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/YEL WIRE
DK GRN/YEL WIRE
EVAPORATOR DISCHARGE AIR TEMPERATURE SENSOR (RIGHT REAR FRAME RAIL)
FPMP CNTRL
FPMP FEED
FPMP RLY
FUEL PUMP RELAY
FUEL TANK PRESSURE TRANSDUCER SENSOR (ON FUEL TANK)
FUSE 18
FUSE 28
FUSE 38
GROUND
GRY WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEATED POSITIVE CRANKCASE VENTILATION (PCV) VALVE (RIGHT SIDE OF ENGINE)
HOT AT ALL TIMES
HOT IN RUN OR START
INERTIA FUEL SHUTOFF (IFS) SWITCH (RIGHT KICK PANEL)
JUNCTION CONNECTOR 1
LT BLU/ORG WIRE
LT BLU/RED WIRE
LT GRN/BLK WIRE
MASS AIRFLOW SENSOR (LEFT SIDE OF ENGINE COMT)
MONITOR
NCA WIRE
PNK/BLK WIRE
RED WIRE
RED/PNK WIRE
RETURN
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
TAN WIRE
TAN/LT BLU WIRE
TAN/ORG WIRE
TAN/YEL WIRE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/ DK BLU WIRE
WHT/RED WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l (2 of 6) -> FPMP CNTRL
