Mercury Montego III (2004-2007) (five hundred/montego: in rear view inside mirror harn, Wiring diagram
This page shows the only wiring diagram for the component.(five hundred/montego: in rear view inside mirror harn,, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (five hundred/montego: in rear view inside mirror harn, (1 of 1)
BATTERY BATTERY SAVER SAVER RELAY RELAY
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/LT BLU WIRE
COURTESY LAMP RELAY
FUSE 1
FUSE 2
HOME- LINK MODULE
HOT AT ALL TIMES
LEFT VANITY MIRROR LAMP
LOW CURRENT BOARD
LT GRN/ORG WIRE
LUGGAGE COMPARTMENT LAMP (FIVE HUNDRED, MONTEGO)
ORG/ WIRE
RED WIRE
RIGHT VANITY MIRROR LAMP
SECOND ROW SEAT INTERIOR/MAP LAMP ASSEMBLY
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
THIRD ROW SEAT INTERIOR/MAP LAMP ASSEMBLY (FREESTYLE)
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> (FIVE HUNDRED/MONTEGO: IN REAR VIEW INSIDE MIRROR HARN,
