Mercury Montego III (2004-2007) +/- +/- diag gnd Wiring diagram
This page shows the only wiring diagram for the component.+/- +/- diag gnd, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +/- +/- diag gnd (1 of 1)
+/- +/- DIAG GND
ACCESSORY RELAY
BATTERY JUNCTION BOX(BJB) (LEFT FRONT OF ENGINE COMPARTMENT)
BLK WIRE
BRN/LT BLU WIRE
CIRCUIT BREAKER 25
DN UP DN
DN UP UP
DN UP UP DN
DN UP UP DN UP DN
DRIVER SIDE POWER WINDOW MOTOR
DRIVER WINDOW SWITCH
FUSE 15
FUSE 30
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT REAR WINDOW ADJUST SWITCH
LEFT REAR WINDOW SWITCH
LOW CURRENT BOARD
MASTER WINDOW ADJUST SWITCH
ONE TOUCH DOWN SWITCH
ORG/YEL WIRE
PASSENGER SIDE WINDOW ADJUST SWITCH
PASSENGER WINDOW SWITCH
PNK/LT GRN WIRE
RED/BLK WIRE
RED/LT BLK WIRE
RED/LT BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR POWER WINDOW MOTOR (RIGHT REAR DOOR)
RIGHT REAR WINDOW ADJUST SWITCH
RIGHT REAR WINDOW SWITCH
SMART JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UP AUTO DOWN
UP DN
USED FOR DIAGNOSTIC ONLY
VPWR VBATT
WHT/BLK WIRE
WHT/LT BLU WIRE
WINDOW LOCKOUT SWITCH
YEL WIRE
YEL/BLK WIRE
