Mercury Montego III (2004-2007) auxiliary relay box 2 Wiring diagram
This page shows the only wiring diagram for the component.auxiliary relay box 2, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary relay box 2 (1 of 1)
A/C CLUTCH RELAY
AUXILIARY COOLANT PUMP RELAY
AUXILIARY RELAY BOX 1
AUXILIARY RELAY BOX 2
AUXILIARY RELAY BOX 3
BATTERY JUNCTION BOX (BJB)
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRN WIRE
DK BLU WIRE
ELECTRO- CHROMATIC INSIDE MIRROR UNIT
ELECTRONIC COMPASS
FLOOR SHIFTER
FOG LAMP RELAY
FROM FUSE 21 (BATTERY JUNCTION BOX) (DIAGRAM 1 OF 3)
FUEL PUMP RELAY
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 28
FUSE 32
FUSE 34
FUSE 36
FUSE 4
GRN WIRE
GRY WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER
JOINT CONNECTOR 2 (LEFT FRONT OF ENGINE COMPT)
KEY REMOVAL INHIBIT SOLENOID
KEY-IN IGNITION SWITCH
LT BLU WIRE
LT GRN WIRE
OFF
ORG/ WIRE
PCM POWER RELAY
PNK WIRE
POWERTRAIN CONTROL MODULE
RADIO
RED WIRE
RUN WIRE
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
STARTER RELAY
TAN WIRE
TO FUSE 20 SMART JUNCTION BOX (DIAGRAM 3 OF 3)
VIO WIRE
WHT WIRE
WINDSHIELD WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> AUXILIARY RELAY BOX 2
