Mercury Montego III (2004-2007) 18 3 dr unlock ctrl dr lock ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. 18 3 dr unlock ctrl dr lock ctrl, in which he is found in the car Mercury Montego III (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
18 3 dr unlock ctrl dr lock ctrl wiring diagram (1 of 2)
1/2
18 3 DR UNLOCK CTRL DR LOCK CTRL
3/4
5/6
7/8
9/0
AJAR SW SIG
BLK WIRE
DECKLID RELAY
DECKLID SOLENOID (EXCEPT FREESTYLE) (CENTER OF DECKLID)
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR UNLOCK RELAY
DRIVER SIDE DOOR LOCK SWITCH
EXC FREESTYLE
FREESTYLE
FUSE 3
HOT AT ALL TIMES
KEY PAD A SIG
KEY PAD B SIG
KEY PAD C SIG
KEY PAD ILLUM
KEY PAD SWITCH ASSEMBLY
LEFT FRONT DOOR LOCK ACTUATOR (LEFT FRONT DOOR)
LIFTGATE AJAR SWITCH (FREESTYLE) (BOTTOM OF LIFTGATE)
LIFTGATE LOCK ACTUATOR (FREESTYLE) (IN LIFTGATE)
LOCK
LOW CURRENT BOARD
LT BLU WIRE
LT BLU/YEL WIRE
NEAR BREAK-
PASSENGER SIDE DOOR LOCK SWITCH
PNK PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/LT GRN WIRE
PNK/YEL WIRE
REAR WIPER MOTOR ASSEMBLY (FREESTYLE) (CENTER OF LIFTGATE)
RED WIRE
RED/LT BLU WIRE
RIGHT REAR DOOR LOCK ACTUATOR (RIGHT REAR DOOR)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
UNLOCK
VIO WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Door lock circuit (1 of 2) -> 18 3 DR UNLOCK CTRL DR LOCK CTRL
18 3 dr unlock ctrl dr lock ctrl wiring diagram (2 of 2)
1/2
18 3 DR UNLOCK CTRL DR LOCK CTRL
3/4
5/6
7/8
9/0
AJAR SW SIG
BLK WIRE
DECKLID RELAY
DECKLID SOLENOID (EXCEPT FREESTYLE) (CENTER OF DECKLID)
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR UNLOCK RELAY
DRIVER SIDE DOOR LOCK SWITCH
EXC FREESTYLE
FREESTYLE
FUSE 3
HOT AT ALL TIMES
KEY PAD A SIG
KEY PAD B SIG
KEY PAD C SIG
KEY PAD ILLUM
KEY PAD SWITCH ASSEMBLY
LEFT FRONT DOOR LOCK ACTUATOR (LEFT FRONT DOOR)
LIFTGATE AJAR SWITCH (FREESTYLE) (BOTTOM OF LIFTGATE)
LIFTGATE LOCK ACTUATOR (FREESTYLE) (IN LIFTGATE)
LOCK
LOW CURRENT BOARD
LT BLU WIRE
LT BLU/YEL WIRE
NEAR BREAK-
PASSENGER SIDE DOOR LOCK SWITCH
PNK PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/LT GRN WIRE
PNK/YEL WIRE
REAR WIPER MOTOR ASSEMBLY (FREESTYLE) (CENTER OF LIFTGATE)
RED WIRE
RED/LT BLU WIRE
RIGHT REAR DOOR LOCK ACTUATOR (RIGHT REAR DOOR)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
UNLOCK
VIO WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Forced entry circuit (1 of 2) -> 18 3 DR UNLOCK CTRL DR LOCK CTRL
