Mercury Montego III (2004-2007) 1 2 3 4 5 6 7 8 9 10 gnd sw com rel out tilt sig open sig bat Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 7 8 9 10 gnd sw com rel out tilt sig open sig bat, which is found in the car Mercury Montego III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 7 8 9 10 gnd sw com rel out tilt sig open sig bat (1 of 1)
1 2 3 4 5 6 7 8 9 10 GND SW COM REL OUT TILT SIG OPEN SIG BAT
ACCESSORY DELAY RELAY
AUTO OPEN
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENG COMPT)
BLK WIRE
BRN/ORG WIRE
CLOSE OPEN
CLOSE SIG
DK BLU WIRE
FUSE 15
FUSE 25
FUSE 6
HOT AT ALL TIMES
LOW CURRENT BOARD
LT BLU WIRE
OVERHEAD CONSOLE
RED WIRE
RED/LT BLU WIRE
ROOF OPENING PANEL MODULE (ABOVE REAR VIEW MIRROR)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
TAN/RED WIRE
TILT
WHT/RED WIRE
Go to component -> Power top/sunroof circuit -> 1 2 3 4 5 6 7 8 9 10 GND SW COM REL OUT TILT SIG OPEN SIG BAT
