Power seat circuit, 8-way passenger seat for Mercury Milan I (2005-2010)
Power seat circuit, 8-way passenger seat
AFT
BASE
BATTERY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
DOWN UP
FORE TILT DOWN TILT UP
FRONT
FRONT PASSENGER SEAT LUMBAR MOTOR (RIGHT SIDE OF SEAT)
FRONT PASSENGER SEAT RECLINER MOTOR (RIGHT SIDE OF SEAT)
FRONT UP/DOWN
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LUMBAR
ORG/ WIRE
OUT
PASSENGER SIDE FRONT SEAT ADJUST SWITCH
REAR
REAR UP/DOWN FWD/BACK RIGHT POWER SEAT MOTOR ASSEMBLY (UNDER SEAT BOTTOM)
RECLINE
RED WIRE
TILT DOWN
TILT UP
VIO WIRE
WHT WIRE
YEL WIRE
