Power door locks circuit, with memory for Mercury Milan I (2005-2010)
Power door locks circuit, with memory (1 of 2)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BREAKOUT TO SMART JUNCTION BOX (SJB))
BRN WIRE
DRIVER SIDE DOOR LOCK SWITCH
DRIVER'S DOOR MODULE (FRONT OF DRIVER'S DOOR)
FUSE 16
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT REAR DOOR)
LOCK
LOCK ALL RELAY
LR DOOR AJAR
PASS TRIM DOOR UNLOCK LOCK AJAR
PASSENGER SIDE DOOR LOCK SWITCH
RED WIRE
RESET+
RIGHT FRONT DOOR LOCK ACTUATOR (IN RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT REAR DOOR)
RR DOOR PILLAR) AJAR
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" LOGIC
TRIM)
UNLOCK
UNLOCK ALL RELAY
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
YEL WIRE
Power door locks circuit, with memory (2 of 2)
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BRN WIRE
COMPARTMENT)
DISARM REQUEST
DRIVER DOOR AJAR
GRN WIRE
GRY WIRE
HOOD AJAR
KEYPAD
KEYPAD ILLUM
KEYPAD SWITCH ASSEMBLY
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S DOOR)
ORG/ WIRE
RESET+
SET-
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR) LOGIC
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
