Mercury Milan I (2005-2010) right left down up Wiring diagram
This page shows the only wiring diagram for the component.right left down up, which is found in the car Mercury Milan I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right left down up (1 of 1)
BLK/WHT WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DOWN UP
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
GRY WIRE
HOT AT ALL TIMES
LEFT RIGHT
LEFT SIDE EXTERIOR REAR VIEW MIRROR
LEFT/ RIGHT UP/ DOWN
RIGHT LEFT
RIGHT LEFT DOWN UP
RIGHT SIDE EXTERIOR REAR VIEW MIRROR
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR)
WHT/RED WIRE
YEL/VIO WIRE
Go to component -> Power mirrors circuit -> RIGHT LEFT DOWN UP
