Mercury Milan I (2005-2010) 15 14 swc 2 rtn swc 2 + Wiring diagrams
This page contains all the electrical diagrams for the component. 15 14 swc 2 rtn swc 2 +, in which he is found in the car Mercury Milan I (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
15 14 swc 2 rtn swc 2 + wiring diagram (1 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 MS CAN+
15 14 SWC 2 RTN SWC 2 +
ACCESSORY PROTOCOL INTERFACE MODULE (APIM)
BATT AUDIO SHLD STEREO L(-) STEREO R(-)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/WHT WIRE
CLOCKSPRING
COAX
COAX DCBIAS/ANT
COMPUTER DATA LINES SYSTEM
END
FUSE 20
GRN/ORG WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT SPEAKER
LEFT FRONT TWEETER
MEDIA
NCA WIRE
PUSH
PWR GND
RIGHT FRONT SPEAKER
RIGHT FRONT TWEETER
RIGHT STEERING WHEEL SWITCH
SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE (RIGHT REAR OF TRUNK)
SEEK
SEND
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR)
STEREO L(+) STEREO R(+) MS CAN(-)
TWISTED PAIR WIRES
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE
VOL (-)
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component -> Audiophile sound radio circuit, with sync (2 of 2) -> 15 14 SWC 2 RTN SWC 2 +
15 14 swc 2 rtn swc 2 + wiring diagram (2 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 MS CAN+
15 14 SWC 2 RTN SWC 2 +
ACCESSORY DELAY RELAY
ACCESSORY PROTOCOL INTERFACE MODULE (APIM)
AM ANT FM ANT DEF PWR
AM ANTENNA
ANT PWR
ANT PWR SAT ANT ANT COAX COAX
ANTENNA (FUSION, MILAN) (BASE OF RIGHT "C" PILLAR)
ANTENNA MODULE (MKZ: RIGHT REAR OF TRUNK)
AUDIO CONTROL MODULE (ACM) (CENTER OF DASH)
AUDIO INPUT JACK (IN CENTER CONSOLE)
BATT AUDIO SHLD STEREO L(-) STEREO R(-)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BOX (SJB) (BASE OF LEFT "A" PILLAR)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CIRCUIT BREAKER
CLOCKSPRING
COAX ANT
COAX COAX
COAX DCBIAS/ANT
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
END
FM ANTENNA
FUSE
FUSE 18
FUSE 20
FUSE 22
FUSE 3
GRN WIRE
GRN/ORG WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LF SPKR + SUBWOOFER + SUBWOOFER + RF SPKR + RF SPKR - PWR GND
LF SPKR - SUBWOOFER - SUBWOOFER -
LOGIC
MEDIA
MIC IN+ MIC IN-
MIRRORS SYSTEM
MS CAN - MS CAN +
NCA WIRE
PUSH
PWR GND
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RIGHT STEERING WHEEL SWITCH
SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE (RIGHT REAR OF TRUNK)
SEEK
SEND
SHIELD
SMART JUNCTION
STEREO L(+) STEREO R(+) MS CAN(-)
SWC 2 - SWC 2 + SWC 1 + SWC 1 RTN
TWISTED PAIR WIRES
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VOICE
VOL (-)
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Base radio circuit, with sync -> 15 14 SWC 2 RTN SWC 2 +
15 14 swc 2 rtn swc 2 + wiring diagram (3 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 MS CAN+
15 14 SWC 2 RTN SWC 2 +
ACCESSORY PROTOCOL INTERFACE MODULE (APIM)
BATT AUDIO SHLD STEREO L(-) STEREO R(-)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/WHT WIRE
CLOCKSPRING
COAX
COAX DCBIAS/ANT
COMPUTER DATA LINES SYSTEM
END
FUSE 20
GRN/ORG WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT SPEAKER
LEFT FRONT TWEETER
MEDIA
NCA WIRE
PUSH
PWR GND
RIGHT FRONT SPEAKER
RIGHT FRONT TWEETER
RIGHT STEERING WHEEL SWITCH
SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE (RIGHT REAR OF TRUNK)
SEEK
SEND
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR)
STEREO L(+) STEREO R(+) MS CAN(-)
TWISTED PAIR WIRES
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE
VOL (-)
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component -> Premium radio circuit, with sync (2 of 2) -> 15 14 SWC 2 RTN SWC 2 +
