Electrochromic mirror circuit, late production for Mercury Mariner II (2007-2010)
Electrochromic mirror circuit, late production
3.0L EXCEPT 3.0L
A/T
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
COMPASS
ELECTROCHROMATIC REAR VIEW MIRROR
EXCEPT HYBRID
EXCEPT HYBRID HYBRID
FUSE
FUSE 41
FUSE 7
GRN/BLU WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
INSTRUMENT CLUSTER (IC)
M/T
OF ENGINE COMPT)
POWER
REVERSE
REVERSE LAMP RELAY
REVERSING LAMPS SWITCH (TOP OF TRANSMISSION)
RLC
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
WHT/RED WIRE
YEL/GRN WIRE
YEL/GRY WIRE
