Backup lamps circuit, hybrid for Mercury Mariner II (2007-2010)
Backup lamps circuit, hybrid
BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
EARLY PRODUCTION
ELECTROCHROMATIC REAR VIEW MIRROR
ELECTROCHROMATIC REAR VIEW MIRROR (CENTER OF WINDSHIELD)
FUSE 35
FUSE 7
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LATE PRODUCTION
LEFT REVERSING LAMP
PARKING AID MODULE (PAM) (RIGHT SIDE OF CARGO AREA)
POWERTRAIN CONTROL MODULE (PCM) (REAR CENTER OF FIREWALL)
RED WIRE
REVERSE IN
REVERSE LAMP RELAY
RIGHT REVERSING LAMP
RLC
WHT WIRE
YEL WIRE
