Mercury Mariner II (2007-2010) Cooling fan circuit, hybrid

26 23 11 38 33 37 ACPSW CAN- CAN+ 41 33 SIGRTNE CHT BATTERY JUNCTION BOX (BJB) BLK/GRN WIRE BLK/GRY WIRE BLU/GRY WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CYLINDER HEAD TEMPERATURE SENSOR (TOP OF ENGINE) DUAL PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT, NEAR STRUT TOWER) ENGINE COMPT) ENGINE COOLING FAN DROPPING RESISTOR 1 (LEFT FRONT OF ENGINE COOLING FAN MOTOR 1 ENGINE COOLING FAN MOTOR 2 FAN CONTROL RELAY 1 FAN CONTROL RELAY 2 FAN CONTROL RELAY 3 FUSE 16 FUSE 17 FUSE 27 GRN/BLU WIRE GRN/BRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN RUN OR START BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT) PCM POWER DIODE PCM POWER RELAY POWERTRAIN CONTROL MODULE (PCM) (REAR CENTER OF FIREWALL) RED WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL/ORG WIRE
