Mercury Mariner II (2007-2010) left steering wheel/ speed control switch Wiring diagram
This page shows the only wiring diagram for the component.left steering wheel/ speed control switch, which is found in the car Mercury Mariner II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left steering wheel/ speed control switch (1 of 1)
AMBIENT LIGHTING SWITCH
BACKLIGHTING LED (FET)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BLUE
BRN WIRE
CLOCKSPRING (IN STEERING COLUMN)
DEFEAT
DIM DEFEAT OFF DIM
DIM SW
DIMMER GND SW
DOME DEFEAT
FLOOR SHIFTER
FUSE
HOT AT ALL TIMES
ILLUMINATION DIMMER
LEFT STEERING WHEEL/ SPEED CONTROL SWITCH
LOGIC
MAIN LIGHT SWITCH
MESSAGE CENTER SWITCH
NCA WIRE
OFF
RIGHT STEERING WHEEL/ SPEED CONTROL SWITCH
RPA
SMART JUNCTION BOX (SJB)
TCS
TRACTION ASSIST/ PARKING AID DISABLE SWITCH
VIO/GRY WIRE
WHT/BRN WIRE
Go to component -> Instrument illumination circuit, except hybrid -> LEFT STEERING WHEEL/ SPEED CONTROL SWITCH
