Mercury Mariner II (2007-2010) (in body wiring Wiring diagrams
This page contains all the electrical diagrams for the component. (in body wiring, in which he is found in the car Mercury Mariner II (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
(in body wiring wiring diagram (1 of 3)
3.0L
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/WHT WIRE
EARLY PRODUCTION
ELECTROCHROMATIC REAR VIEW MIRROR (CENTER OF WINDSHIELD)
FUSE 35
FUSE 7
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LATE PRODUCTION
LEFT REVERSING LAMP
PARKING AID MODULE (PAM) (RIGHT REAR SIDE OF VEHICLE)
RED WIRE
REVERSE IN
REVERSE LAMP RELAY
RIGHT REVERSING LAMP
WHT WIRE
YEL WIRE
Go to component -> Backup lamps circuit, a/t except hybrid -> (IN BODY WIRING
(in body wiring wiring diagram (2 of 3)
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/WHT WIRE
FUSE 35
FUSE 7
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT REVERSING LAMP
PARKING AID MODULE (PAM) (RIGHT REAR SIDE OF VEHICLE)
RED WIRE
REVERSE IN
REVERSE LAMP RELAY
REVERSING LAMPS SWITCH (TOP OF TRANSMISSION)
RIGHT REVERSING LAMP
WHT WIRE
YEL WIRE
Go to component -> Backup lamps circuit, m/t except hybrid -> (IN BODY WIRING
(in body wiring wiring diagram (3 of 3)
AMBER
ANTI-LOCK BRAKES SYSTEM
BATTERY JUNCTION
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLUE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 35
FUSE 7 BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ISO
LEFT INNER PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
LEFT OUTER PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
ON/OFF SW
PARKING AID MODULE (PAM) (RIGHT REAR SIDE OF VEHICLE)
PARKING AID SPEAKER
REAR SENS GND
REAR SENS PWR
RED WIRE
REVERSE IN
REVERSE LAMP RELAY
RIGHT INNER PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIGHT OUTER PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIL SENS IN
RIR SENS IN
ROL SENS IN
ROR SENS IN
RPA
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
SPEAKER
STATUS LED
TCS BLUE
TRACTION ASSIST/PARKING AID DISABLE SWITCH
VIO/GRY WIRE
VPRW
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit, except hybrid -> (IN BODY WIRING
