Mercury Mariner II (2007-2010) fuel sndr rtn Wiring diagram

1 2 3 4 5 6 FPM FPRTN GND FPPWR IFS INPUT FP AIR CONDITIONING SYSTEM BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT) BLK WIRE BLK/GRN WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE BOO FTPT CGND HS CAN + FPM CANVNT BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM CRUISE CONTROL SYSTEM EVAPORATIVE EMISSION (EVAP) CANISTER PURGE VALVE (REAR OF ENGINE COMPT) EVMV VPWR VPWR FTV SCCSRTN FUEL GAUGE SENSOR FUEL PUMP FUEL PUMP DRIVER MODULE (UNDER LEFT CENTER OF VEHICLE) FUEL SNDR RTN FUEL SNDR SIG FUEL TANK UNIT (UNDER LEFT REAR OF VEHICLE, IN FUEL TANK) FUSE 13 FUSE 2 FUSE 5 FUSE 8 GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES HS CAN+ IAT BVREF SIGRTN IGNITION SWITCH INERTIA FUEL SHUT-OFF (IFS) SWITCH (RIGHT KICK PANEL) INSTRUMENT CLUSTER (IC) MAF MAFRTN FEPS VBATT MFP GND GND GND GND NCA WIRE OFF POWERTRAIN CONTROL MODULE (PCM) (REAR CENTER OF FIREWALL) RUN WIRE SCCS BPS VPWR ISP-R HS CAN - BPO ACCR ACPSW PSR SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH) TO HIGH VOLTAGE CUTOFF SWITCH (DIAGRAM 6 OF 6) TO TRACTION BATTERY CONTROL MODULE (DIAGRAM 6 OF 6) VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
