Mercury Mariner II (2007-2010) fog auto in lp off on Wiring diagram
This page shows the only wiring diagram for the component.fog auto in lp off on, which is found in the car Mercury Mariner II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fog auto in lp off on (1 of 1)
AIR CONDITIONING SYSTEM
AUTO 1
AUTO- LP
AUTOLAMP SENSOR (CENTER OF DASH)
AUTOLAMP/ SUNLOAD SENSOR (CENTER OF DASH)
AUTOMATIC A/C
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FLASH TO HIGH MS MS PASS LOW BEAM CAN+
FOG
FOG AUTO IN LP OFF ON
FOG IND
FOG LAMP RELAY
FTP
FUSE 21
FUSE 23
FUSE 7
FUSE 8
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HIGH BEAM RELAY
HOT AT ALL TIMES
INSTRUMENT CLUSTER (IC)
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT LOW BEAM (FET)
LOGIC
MAIN LIGHT SWITCH
MANUAL A/C
MS CAN +
MULTI- FUNCTION SWITCH (IN STEERING COLUMN)
OFF
PARK
PARK BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
PARK CAN- BRK
PARK ON
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT LOW BEAM (FET)
SMART JUNCTION BOX (SJB)
SOLID STATE CONTROL
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Headlights circuit, except hybrid -> FOG AUTO IN LP OFF ON
