Mercury Mariner II (2007-2010) electrochromatic rear view mirror Wiring diagrams

BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT) BLK WIRE BLU WIRE BLU/WHT WIRE EARLY PRODUCTION ELECTROCHROMATIC REAR VIEW MIRROR ELECTROCHROMATIC REAR VIEW MIRROR (CENTER OF WINDSHIELD) FUSE 35 FUSE 7 GRN WIRE GRN/BLU WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START LATE PRODUCTION LEFT REVERSING LAMP PARKING AID MODULE (PAM) (RIGHT SIDE OF CARGO AREA) POWERTRAIN CONTROL MODULE (PCM) (REAR CENTER OF FIREWALL) RED WIRE REVERSE IN REVERSE LAMP RELAY RIGHT REVERSING LAMP RLC WHT WIRE YEL WIRE

3.0L EXCEPT 3.0L A/T BLK/GRN WIRE BLK/GRY WIRE BLU/WHT WIRE ELECTROCHROMATIC REAR VIEW MIRROR EXCEPT HYBRID EXCEPT HYBRID HYBRID FUSE FUSE 7 GRN/BLU WIRE GRY WIRE HOT AT ALL TIMES HOT IN START OR RUN SMART JUNCTION FUSE 43 BOX (SJB) (BELOW CENTER OF DASH) M/T OF ENGINE COMPT) POWER REVERSE REVERSE LAMP RELAY REVERSING LAMPS SWITCH (TOP OF TRANSMISSION) RLC WHT/RED WIRE YEL/GRY WIRE

3.0L EXCEPT 3.0L A/T BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE COMPASS ELECTROCHROMATIC REAR VIEW MIRROR EXCEPT HYBRID EXCEPT HYBRID HYBRID FUSE FUSE 41 FUSE 7 GRN/BLU WIRE HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED INSTRUMENT CLUSTER (IC) M/T OF ENGINE COMPT) POWER REVERSE REVERSE LAMP RELAY REVERSING LAMPS SWITCH (TOP OF TRANSMISSION) RLC SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH) WHT/RED WIRE YEL/GRN WIRE YEL/GRY WIRE

15 30 3 28 HS CAN + HS CAN - BFLS GND BFLS 6 7 COMPASS + COMPASS - AJAR AJAR LIFTGATE BACKLIGHTING LED (FET) BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR) CENTER SW SENDER IN COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ANTI-THEFT SYSTEM DF DOOR AJAR DR DOOR AJAR DRIVER SIDE FRONT DOOR LOCK UNIT EARLY PRODUCTION ELECTROCHROMATIC REAR VIEW MIRROR ELECTRONIC COMPASS 3 4 1 2 PWR GND COMPASS + COMPASS - FUEL TANK UNIT (UNDER LEFT REAR OF VEHICLE, IN FUEL TANK) FUSE 10 FUSE 26 FUSE 29 FUSE 31 FUSE 43 FUSE 27 GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN START OR RUN HS CAN- HS CAN+ COMPASS + COMPASS - IGNITION SWITCH INFO INSTRUMENT CLUSTER (IC) KEY-IN IGN LATE PRODUCTION LEFT REAR DOOR LOCK ACTUATOR (IN LEFT REAR DOOR) LIFTGATE AJAR SWITCH (BOTTOM CENTER OF LIFTGATE) LIFTGATE GLASS AJAR SWITCH (CENTER OF LIFTGATE) MAIN LIGHT SWITCH MESSAGE CENTER SWITCH MS CAN + OF ENGINE BLOCK) OIL PRESSURE SWITCH (LOWER LEFT REAR OIL SW GND BULB GND CENTER RTN SENDER RTN PARK BRAKE SW PARK BRAKE SWITCH (BASE OF PARK BRAKE LEVER) PASSENGER SIDE FRONT DOOR LOCK UNIT (REAR OF RIGHT FRONT DOOR) PF DOOR AJAR PR DOOR AJAR RESET+ RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT REAR DOOR) RUN/ACC SET UP SMART LOGIC JUNCTION BOX (SJB) (BELOW CENTER OF DASH) VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
