Mercury Mariner II (2007-2010) brn/blu Wiring diagrams
This page contains all the electrical diagrams for the component. brn/blu, in which he is found in the car Mercury Mariner II (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
brn/blu wiring diagram (21 of 40)
AUTO
BLK/BLU WIRE
BLK/GRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BOO
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FTP
FUSE 22
FUSE 6
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM (BEHIND RIGHT SIDE OF DASH)
GRY/BRN WIRE
GRY/ORG WIRE
HAZARD
HIGH BEAM
HOT AT ALL TIMES
LAMP ON
LEFT FRONT PARK/ TURN LAMP
LEFT FRONT SIDE LAMP (ESCAPE)
LEFT HEADLAMP
LEFT SIDE TURN SIGNAL LAMP (MARINER)
LF TURN
LF TURN LAMP (FET)
LH TURN
LO BEAM
LOGIC
LR STOP/ TURN LAMP
LR STOP/ TURN LAMP (FET)
MAIN LIGHT SWITCH
MS CAN +
PARK
PARK LAMP RELAY
PARK OFF
RF TURN
RF TURN LAMP (FET)
RH TURN
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE LAMP (ESCAPE)
RIGHT SIDE TURN SIGNAL LAMP (MARINER)
RR STOP/ TURN LAMP
RR STOP/ TURN LAMP (FET)
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
TURN
VIO/ORG WIRE
VIO/WHT WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit, except hybrid (1 of 2) -> BRN/BLU WIRE
brn/blu wiring diagram (22 of 40)
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BOO
BOO/STOP
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
BREAKOUT TO LEFT FRONT SIDE LAMP)
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FTP HIGH
FTP SWITCH
FUSE
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BRN WIRE
HAZARD SWITCH
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/STOP/
LT GRN WIRE
OF FIREWALL)
PARK
RED WIRE
REST ON/OFF
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/STOP/
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
SPEED CONTROL SERVO (RIGHT SIDE OF ENGINE COMPT)
STOP TURN
STOP/ TURN PARK
TRAILER TOW LEFT TURN RELAY
TRAILER TOW PARK LAMP RELAY
TRAILER TOW RIGHT TURN RELAY
TURN LAMP
TURN SIGNAL SWITCH
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit, except hybrid (2 of 2) -> BRN/BLU WIRE
brn/blu wiring diagram (23 of 40)
AUTO
BLK/BLU WIRE
BLK/GRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BOO
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FTP
FUSE 22
FUSE 6
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM (BEHIND LEFT END OF DASH)
GRY/BRN WIRE
GRY/ORG WIRE
HAZARD
HIGH BEAM
HOT AT ALL TIMES
LEFT FRONT PARK/ TURN LAMP
LEFT FRONT SIDE LAMP (ESCAPE)
LEFT SIDE TURN SIGNAL LAMP (MARINER)
LF TURN
LF TURN LAMP (FET)
LH TURN
LO BEAM
LOGIC
LR STOP/ TURN LAMP
LR STOP/ TURN LAMP (FET)
MAIN LIGHT SWITCH
MS CAN +
PARK
PARK LAMP ON
PARK LAMP RELAY
PARK OFF
RF TURN
RF TURN LAMP (FET)
RH TURN
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE LAMP (ESCAPE)
RIGHT SIDE TURN SIGNAL LAMP (MARINER)
RR STOP/ TURN LAMP
RR STOP/ TURN LAMP (FET)
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
TURN
VIO/ORG WIRE
VIO/WHT WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit, hybrid (1 of 2) -> BRN/BLU WIRE
brn/blu wiring diagram (24 of 40)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BOO
BRAKE PEDAL POSITION (BPP) SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FTP HIGH
FTP SWITCH
FUSE
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BRN WIRE
HAZARD SWITCH
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/STOP/
LT GRN WIRE
PARK
POWERTRAIN CONTROL MODULE (PCM) (REAR CENTER OF FIREWALL)
RED WIRE
REST ON/OFF
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/STOP/
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
STOP TURN
TURN LAMP
TURN SIGNAL SWITCH
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit, hybrid (2 of 2) -> BRN/BLU WIRE
brn/blu wiring diagram (25 of 40)
AIR CONDITIONING SYSTEM
AUTO 1
AUTO- LP
AUTOLAMP SENSOR (CENTER OF DASH)
AUTOLAMP/ SUNLOAD SENSOR (CENTER OF DASH)
AUTOMATIC A/C
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FLASH TO HIGH MS MS PASS LOW BEAM CAN+
FOG
FOG AUTO IN LP OFF ON
FOG IND
FOG LAMP RELAY
FTP
FUSE 21
FUSE 23
FUSE 7
FUSE 8
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HIGH BEAM RELAY
HOT AT ALL TIMES
INSTRUMENT CLUSTER (IC)
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT LOW BEAM (FET)
LOGIC
MAIN LIGHT SWITCH
MANUAL A/C
MS CAN +
MULTI- FUNCTION SWITCH (IN STEERING COLUMN)
OFF
PARK
PARK BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
PARK CAN- BRK
PARK ON
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT LOW BEAM (FET)
SMART JUNCTION BOX (SJB)
SOLID STATE CONTROL
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Headlights circuit, except hybrid -> BRN/BLU WIRE
brn/blu wiring diagram (26 of 40)
AIR CONDITIONING SYSTEM
AUTO 1
AUTO- LP
AUTOLAMP/ SUNLOAD SENSOR (UNDER TOP CENTER OF DASH)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FLASH TO HIGH MS LOW PASS BEAM CAN+
FOG
FOG AUTO IN OFF LP ON
FOG IND
FOG LAMP RELAY
FTP
FUSE 21
FUSE 23
FUSE 7
FUSE 8
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HIGH BEAM RELAY
HOT AT ALL TIMES
INSTRUMENT CLUSTER (IC)
LEFT HEADLAMP
LEFT LOW BEAM (FET)
LOGIC
MAIN LIGHT SWITCH
MS CAN +
MULTI- FUNCTION SWITCH
OFF
PARK
PARK BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
PARK CAN- BRK
PARK ON
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT LOW BEAM (FET)
SMART JUNCTION BOX (SJB)
SOLID STATE CONTROL
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Headlights circuit, hybrid -> BRN/BLU WIRE
brn/blu wiring diagram (27 of 40)
AUDIO ENABLE
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER TWEETER
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
DIGITAL SIGNAL PROCSSIONG (DSP) MODULE (RIGHT REAR OF TRUNK COMPT)
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
INSTRUMENT PANEL SPEAKER
LEFT FRONT SPEAKER
LEFT FRONT TWEETER
LEFT MID
LEFT REAR SPEAKER
LEFT THX SUBWOOFER SPEAKER
MEDIA
MS CAN - MS CAN +
NAV IN + NAV IN -
NCA WIRE
REAR CENTER THX SPEAKER
RIGHT FRONT SPEAKER
RIGHT FRONT TWEETER
RIGHT MID
RIGHT REAR SPEAKER
RIGHT STEERING WHEEL SWITCH
RIGHT THX SUBWOOFER SPEAKER
SEEK
TWISTED PAIR WIRES
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE
VOL (-)
W/ NAVIGATION THX AUDIO
W/ VOICE NAVIGATION
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit (2 of 2) -> BRN/BLU WIRE
brn/blu wiring diagram (28 of 40)
AMBER
ANTI-LOCK BRAKES SYSTEM
BATTERY JUNCTION
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLUE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 35
FUSE 7 BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ISO
LEFT INNER PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
LEFT OUTER PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
ON/OFF SW
PARKING AID MODULE (PAM) (RIGHT REAR SIDE OF VEHICLE)
PARKING AID SPEAKER
REAR SENS GND
REAR SENS PWR
RED WIRE
REVERSE IN
REVERSE LAMP RELAY
RIGHT INNER PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIGHT OUTER PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIL SENS IN
RIR SENS IN
ROL SENS IN
ROR SENS IN
RPA
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
SPEAKER
STATUS LED
TCS BLUE
TRACTION ASSIST/PARKING AID DISABLE SWITCH
VIO/GRY WIRE
VPRW
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit, except hybrid -> BRN/BLU WIRE
brn/blu wiring diagram (29 of 40)
AMBER
ANTI-LOCK BRAKES SYSTEM
BATTERY JUNCTION
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLUE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 35
FUSE 7 BOX (BJB) (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ISO
LEFT INNER PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
LEFT OUTER PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
ON/OFF SW
PARKING AID MODULE (RIGHT SIDE OF CARGO AREA)
PARKING AID SPEAKER (RIGHT SIDE OF CARGO AREA)
REAR SENS GND
REAR SENS PWR
RED WIRE
REVERSE IN
REVERSE LAMP RELAY
RIGHT INNER PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIGHT OUTER PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIL SENS IN
RIR SENS IN
ROL SENS IN
ROR SENS IN
RPA
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
SPEAKER
STATUS LED
TCS BLUE
TRACTION ASSIST/PARKING AID DISABLE SWITCH
VIO/GRY WIRE
VPRW
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit, hybrid -> BRN/BLU WIRE
brn/blu wiring diagram (30 of 40)
1/2 3/4
5/6
7/8
ALL LOCK RELAY
ALL UNLOCK RELAY
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
DF DR AJAR
DOOR AJAR
DR LOCK DR UNLOCK PR DR AJAR DR DR AJAR
DRIVER SIDE FRONT DOOR LOCK UNIT DOOR AJAR (IN LEFT STATUS FRONT DOOR)
DRIVER UNLOCK RELAY
FUSE 17
FUSE 24
FUSE 41
FUSE 5
GLASS SW
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HORN RELAY
HORN RLY
HORNS SYSTEM
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
KEY LOCK/ UNLOCK
KEYPAD ILLUMINATION (FET)
KEYPAD SWITCH ASSEMBLY
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT REAR DOOR)
LIFTGATE (FET)
LIFTGATE AJAR SW
LIFTGATE SW
LIFTGLASS RELEASE RELAY
LIFTGLASS RELEASE RLY
LOGIC
PF DR AJAR
RKE RECEIVER INTERNAL ANTENNA
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
SW A SW C SW B
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Power door locks circuit, except hybrid (1 of 2) -> BRN/BLU WIRE
