Mercury Mariner II (2007-2010) breakout to left front side lamp) Wiring diagram
This page shows the only wiring diagram for the component.breakout to left front side lamp), which is found in the car Mercury Mariner II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram breakout to left front side lamp) (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BOO
BOO/STOP
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
BREAKOUT TO LEFT FRONT SIDE LAMP)
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FTP HIGH
FTP SWITCH
FUSE
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BRN WIRE
HAZARD SWITCH
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/STOP/
LT GRN WIRE
OF FIREWALL)
PARK
RED WIRE
REST ON/OFF
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/STOP/
SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH)
SPEED CONTROL SERVO (RIGHT SIDE OF ENGINE COMPT)
STOP TURN
STOP/ TURN PARK
TRAILER TOW LEFT TURN RELAY
TRAILER TOW PARK LAMP RELAY
TRAILER TOW RIGHT TURN RELAY
TURN LAMP
TURN SIGNAL SWITCH
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit, except hybrid (2 of 2) -> BREAKOUT TO LEFT FRONT SIDE LAMP)
