Mercury Mariner II (2007-2010) 41 3 sig rtn vss wiring diagram
This page shows the only wiring diagram for the component.41 3 sig rtn vss, which is found in the car Mercury Mariner II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
41 3 sig rtn vss wiring diagram (1 of 1)
3.0L
41 1 SIG RTN VSO
41 3 SIG RTN VSS
50 3 VRSRTN IND CTRL
A/T
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BOO
BPP SW
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
BREAKOUT TO LEFT SIDE TURN SIGNAL LAMP)
BRN WIRE
BRN/GRN WIRE
CLOCKSPRING (IN STEERING COLUMN)
CLUTCH SWITCH (2.3L)
COAST
DEACT- IVATOR SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
ENGINE CONTROLS
FUSE 33
FUSE 34
FUSE 35
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES SMART JUNCTION BOX (SJB) (BELOW CENTER OF DASH) FUSE 2
HOT IN START OR RUN
IND CTRL
M/T
OFF
ORG/ WIRE
OUTPUT SHAFT SPEED (OSS) SENSOR
POWER DISTRIBUTION SYSTEM
REAR WINDOW DEFROST RELAY
RED WIRE
RESUME
SET/ ON ACCEL
SIG RTN
SPEED CONTROL SERVO
STEERING WHEEL/ SPEED CONTROL SWITCH
SW IN
SYSTEM
TSS OSS
TURBINE SHAFT SPEED (TSS) SENSOR
VEHICLE SPEED SENSOR (2.3L) (RIGHT SIDE OF TRANSMISSION)
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
VREF
VSO
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Cruise control circuit, except hybrid -> 41 3 SIG RTN VSS
